Description
Package Contents
Camera
Speakerphone
Remote control
Two 5m/16.4’ cables for connection between speakerphone and hub and camera and hub
One 3m/9.8’ meter cable between hub and PC
Velcro for cable management
Velcro for hub to table securing, powered hub
Power adapter with regional plugs
Mount
Quick start guide
Technical Specifications
Camera:
Smooth motorized pan
Tilt and zoom
Controlled from remote or console 260°pan
130° tilt
10x lossless HD zoom
90° Field of View
Full HD 1080p 30fps
H.264 UVC 1.5 with Scalable Video Coding (SVC)
Autofocus 5 camera presets
Far-end control (PTZ) of ConferenceCam product
ZEISS® lens certification
Kensington security slot
LED to confirm video streaming
Standard tripod thread
Remote control:
Dockable 8.5 m/28-foot range
Speakerphone:
Full-duplex performance
Acoustic echo cancellation
Noise reduction technology
Ultra-wideband audio
Bluetooth® and NFC enabled
LCD for caller ID, call duration and other functional response
LEDs for speakerphone streaming, mute, hold, and Bluetooth
Touch controls for call answer/end, volume and mute, Bluetooth – plus camera PTZ, “home” preset and far-end control
Microphones (Tx)
Four omni-directional microphones supporting 20-foot diameter range
Frequency response: 100Hz – 11KHz
Sensitivity: -28dB +/-3dB
Distortion: <5% from 200Hz
Kensington security slot
Hub / Cable:
Central mountable hub for connection of all components
Included adhesive solution for under-table mounting
Two cables for connection between hub and camera/ speakerphone (Length: 5m/16 ft)
One USB cable for connection to PC/Mac (Length: 2 m/6.6 ft)
AC Power adapter (Length: 3 m/9.8 ft)
Mount:
Dual purpose mount for wall placement or for elevating camera on table
Compliance and tools:
USB 2.0 compliant
UVC-compliant video and audio for broad application compatibility
Skype for Business™ certified, Microsoft® Lync®, Cisco Jabber® and WebEx® compatible
Enhanced integration with Logitech Collaboration Program (LCP) members
Downloadable diagnostic tool
Field upgradeable firmware tool
Downloadable app plug-ins for advanced feature support
